MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

Brand Name : IOTROUTER

Model Number : EG8100

Certification : RoHS, CE FCC RoHS

Place of Origin : Sichuan, CHINA

MOQ : 1PCS

Price : USD139~159/PCS

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50000PCS/MONTH

Delivery Time : 1 WEEK

Packaging Details : 170*170*60mm CARTON PACKAGE

Product Name : PLC Gateway with GPS GSM Antenna

Application : Industrial Automation

Customized : Support

OEM : Support

Factory : Yes

MOQ : 10PCS

Warranty : 2 Year

Material : Steel

Contact Now

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

  • Introduction​ of PLC Gateway

EG8100 series products are edge computing gateways launched by IOTRouter Chengdu. With its rich hardware interfaces, drag-and-drop programming method, Zero Code design concept, convenient remote management and other characteristics, It can quickly, flexibly, accurately and efficiently respond to various IoT industry needs. Edge8000 abstracts complex hardware interfaces, different industrial network protocols, etc. into Nodesone by one. Users can use these Nodes flexibly to replace the traditional complex and inefficient coding process by dragging and connecting. Really let customers focus on business logic and quickly create their own gateway equipment. The mission of Edge8000 is to continuously develop new Nodes to serve industry customers to adapt to the fragmentation of IoT industry needs.

Parameters of PLC Gateway

Serial Port
DO
Number of ports
RS485*2
Number of interfaces
6 Relay output
Standard
RS485: A, B
Standard
DO*6, COM*2
Baud rate
600～921600bps
Mechanical durability
10^7
Data bit
8, 9
Electrical durability
10^5
Stop bit
0.5, 1, 1.5, 2
Capacity
5A 250VAC 30VDC
Check Bit
NONE EVEN ODD
DI
Power Supply
Number of interfaces
6 Relay input
Voltage
9~36V
Standard
DI*6, COM*2
Current
60mA(aver) @9V
30mA(aver) @36V
Detection range (wet node)
5~50V->High0~2V->Low


  • Functions of PLC Gateway

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna

MQTT RS485 PLC Controller Programmable 4G 5G Gateway with GPS GSM Antenna
